Kaishan’s oil free screw air Equipment has precision host produced manufacturing process and technology has high volume ratio, low noise and heat generation, long service life, and noise as low as A) It can be placed next to the gas point to reduce the installation cost. High temperature resistance, normal operation at 55 ℃, convenient installation, low maintenance cost, high quality consumables, long service life, and easy replacement
Energy saving: more than 15% energy saving compared with dry oil-free engine
Environmental protection: no lubricating oil is used to avoid environmental pollution
Reliable: absolute oil free guarantee
As the purified water participates in the sealing, cooling and lubrication in the compression process, the efficiency is greatly improved. The gas production at the same specific power is more than 15% higher than that of the dry oil-free engine, which greatly reduces the energy consumption. Its consumables are only cheap water, air filter element and water filter element, and the maintenance cost is extremely low.
In the process of food and beverage processing, drug manufacturing, packaging, electronic manufacturing, painting, powder coating and textile manufacturing, any risk of oil pollution must be eliminated, otherwise it will lead to serious consequences, damage, production stoppage, brand and credit damage. Simeon oil-free screw Equipment uses pure water as the lubricating medium, and the main engine has no lubricating oil at all. Because of the cleaning effect of pure water on the air, the compressed air produced is absolutely pure, without any pollution.
Oil free air Equipment 11 KW – 250 KW
| Model | Working Pressure | Air Flow | Power | Noise | Weight | Outlet | Size |
| Mpa | m3/min | kw | Db(A) | kg | L*W*H mm | ||
| OGWFD11 | 0.7 | 1.5 | 11 | 58 | 550 | G1 | 1400*865*1150 |
| 0.8 | 1.4 | ||||||
| 1 | 1.2 | ||||||
| OGWFD15 | 0.7 | 2.6 | 15 | 75±3 | 552 | ||
| 0.8 | 2.3 | ||||||
| 1 | 2 | ||||||
| OGWFD22 | 0.7 | 3.5 | 22 | 600 | |||
| 0.8 | 3.2 | ||||||
| 1 | 2.7 | ||||||
| OGWFD30 | 0.7 | 5.2 | 30 | 75±3 | 1030 | G11/2 | 1850*1178*1480 |
| 0.8 | 5 | ||||||
| 1 | 3.6 | ||||||
| OGWFD37 | 0.7 | 6.1 | 37 | ||||
| 0.8 | 5.8 | ||||||
| 1 | 5.1 | ||||||
| OGWD45 | 0.7 | 7.6 | 45 | 75±3 | 1532 | G2 | 1870*1320*1480 |
| 0.8 | 7 | ||||||
| 1 | 6 | ||||||
| OGWD55 | 0.7 | 9.8 | 55 | 1630 | |||
| 0.8 | 9.1 | ||||||
| 1 | 8 | ||||||
| OGWFD45 | 0.7 | 7.6 | 45 | 75±3 | 2200 | G2 | 2100*1470*1700 |
| 0.8 | 7 | ||||||
| 1 | 6 | ||||||
| OGWFD55 | 0.7 | 9.8 | 55 | 2280 | |||
| 0.8 | 9.1 | ||||||
| 1 | 8 | ||||||
| OGW(F)D75 | 0.7 | 13 | 75 | 75±3 | Whole Machine :2270 Air Cooling::650 |
DN65 | Whole Machine:2160*1370*1705 Air Cooling:1450*1450*1666 |
| 0.8 | 12 | ||||||
| 1 | 11 | ||||||
| OGW(F)D90 | 0.7 | 16 | 90 | Whole Machine:2310 Air Coolint :800 |
Whole Machine:2160*1370*1705 Air Cooling:1620*1620*1846 |
||
| 0.8 | 15.8 | ||||||
| 1 | 14 | ||||||
| OGW(F)D110 | 0.7 | 19.6 | 110 | 78±3 | Whole Machine:2695 Air Cooling:800 |
DN80 | Whole Machine:2600*1470*1680 Air Cooling:1620*1620*1846 |
| 0.8 | 18.9 | ||||||
| 1 | 16.5 | ||||||
| OGW(F)D132 | 0.7 | 23.3 | 132 | Whole Machine: 3090 Air Cooling: 800 |
|||
| 0.8 | 21.6 | ||||||
| 1 | 19.3 | ||||||
| OGWD160 | 0.7 | 29 | 160 | 82±4 | 2930 | DN100 | 3410*1865*2190 |
| 0.8 | 28 | ||||||
| OGWD185 | 0.7 | 33.8 | 185 | 2960 | |||
| 0.8 | 31.5 | ||||||
| 1 | 28.8 | ||||||
| OGWD200 | 0.7 | 36 | 200 | 2960 | |||
| 0.8 | 34 | ||||||
| 1 | 30 | ||||||
| OGWD220 | 0.7 | 39 | 220 | 3320 | |||
| 0.8 | 37 | ||||||
| 1 | 33 | ||||||
| OGWD250 | 0.7 | 42.5 | 250 | 3620 | |||
| 0.8 | 41.5 | ||||||
| 1 | 39 |
Note：W means water-lubricated , F means air cooling, without F means water cooling.
KAISHAN’s range of oil-free air Equipments offers 100 percent oil-free compressed air solutions. The oil-free screw air Equipments come with pre-lubricated cylinders coated with a material like PTFE, which helps the piston to slide easily. They are designed to provide zero risks of contamination and improved energy efficiency. In addition, the oil-free range provides long-term reliability to meet the precise needs of a diverse range of industries that cannot tolerate any scope of contamination. Industries such as pharmaceuticals, food & beverage, semiconductor and electronics manufacturing, automotive, and textiles rely on oil-free air Equipments for their operations.
For more options of Kalshang screw Equipments:
Trolley Mounted Screw Equipment
Truck Mounted Equipment for Water Drilling Rigs
For DTH driling rigs & DTH drill bits and hammer:
Kalshang Drilling Rigs Company
KAISHAN is one of the few air Equipment companies to design and manufacture airends for Oil-free Equipment technology. The new OGWD series air Equipments provide disruptive benefits in terms of efficiency, reliability, and air quality resulting in lower life cycle cost and high uptime. In addition, the Class-“0” certified high-quality air makes this Equipment ideal for sensitive applications in pharmaceuticals, food, and beverage industries where the presence of oil vapor and moisture is intolerable.
